CDX-X60 Series
The CDX-X60 is our most extreme precision rifle design yet. Chambered in both 12.7x114mm UA and 14.5x114mm calibers, this amazing rifle is capable of delivering maximum payload at extreme distances when combined with match grade ammunition.
The lack of quality ammunition in these specialty calibers has previously been a problem, but now resolved due to a partnership with two of the most renowned superior quality ammo makers on the planet. These two partners are offering a wide selection of ammunition for recreational shooting or military applications.
± 70" | 178 cm
| Caliber | Barrel length | Twist rate | Rifling type | Magazine capacity | O.A.L.* | O.A.L. FOLDED* | Approx. weight |
|---|---|---|---|---|---|---|---|
| 12.7x114mm UA | 36"/ 40" | 1:13" | 8 | 4 | 60.5" / 64.5" | 50.5" / 54.5" | 43.0 lb / 45.0 lb |
| 14.5x114mm | 40" | 1:14" | 8 | 4 | 64.5" | 54.5" | 45.0 lb |
*Dimensions do not include the muzzle brake.
DISCLAIMER: Too many components are involved to accurately predict the final weight of a rifle. It is impossible to confirm the weight of all our rifle models because it varies depending on each caliber.
For more information, please refer to our Catalog (pdf-format or flipbook), or contact us at customerservice@cadexinc.com
Unidirectional bipod recoil rail to reduce the muzzle rise and improve tracking on follow-up shots
Available Colors
Specifications
2.400” diameter receiver
- Machining: CNC
- Material: Stainless 416
- Length: 14.160"
- Diameter: 2.400"
- Thread: 17/8" - 18 TPI
- Hardness: 41-43 HRC
- .420" hardened steel recoil lug
- Heavy duty 10-32 top rail screws
- Cerakote finish
- 20 MOA stainless steel Picatinny rail
- Cadex proprietary heavy duty bolt stop and pin
- Unique top rail localization system with integrated recoil groove machined into the action upper section
- Cadex proprietary magazine
- Cadex proprietary footprint
- Compatible with the Cadex DX2 EVO trigger or some Rem Style aftermarket triggers
- Deep laser engraving markings
New CDX-X60 custom grade bolt action repeater made from 416 stainless steel. DLC coated 4 lug spiral fluted bolt with ultra-fast 50° bolt throw.
- Machining: CNC
- Material: Stainless 416
- Firing pin: Cadex design with improved locktime
- Cadex heavy duty extractor
- Ejectors: Rem style double ejectors
- Easy ¼ turn tool-free bolt disassembly
- Hardness: 43-45 HRC
- Easy firing pin assembly replacement
- Shroud: Cadex design with 3 position top safety (FIRE, UNLOAD, SAFETY)
- Standard round bolt knob (optional tactical bolt knob sold separately)
- DLC coated spiral fluted bolt
- Cadex design cocking piece
- Bolt face type G (1.082"): 12.7x114mm UA, 14.5x114mm
A: Tactical knob (0.85″ x 2.97″) - sold separately
D: Rounded knob (0.98″ x 2.98″) - included
Bartlein 2.200" straight taper fluted match grade barrel with single point cut rifling technology. 8 groove 36" or 40" long barrel for extended range application. Threaded muzzle for muzzle brake installation (MX3-ST included).
Heavy duty recoil lug.
Heavy duty recoil lug.
Compatible optional accessories
Cerakote Coating
