CDX-R7 LCP Series
The CDX-R7 LCP Series includes all features required by the most demanding PRS competitive shooters. Its folding stock mechanism is a charm when it comes to cleaning and transport. The lightning-fast R7 action with its 4 lugs 50° bolt throw is a must to save time on PRS-style stages. Based on a Rem 700 footprint and combined with a medium contour Bartlein Single Point Cut match grade fluted barrel for optimum performance. Compatible with M-LOK accessories.
RIFLE STOCK FEATURES
Standard recoil pad
Part#: 175-00087-BLK
The Cadex Recoil Pads is designed to deliver comfort and stability with every shot. Whether you’re on the range or in the field, this pad reduces felt recoil, improving overall shooting performance and comfort.
Neoprene cheek pad
Part#: 03127-693-N18
The Neoprene Cheek Pad offers enhanced comfort and durability for precision rifle users. Crafted from high-quality neoprene, this cheek pad enhances cheek weld, reduces fatigue, and improves consistency in your shooting position.
Skeleton stock
Part#: 03127-K007
Cadex Folding Skeleton Stock features a lightweight, durable design that folds for compact transport while providing a stable and comfortable shooting platform. Tool-free adjustments for length of pull, cheek piece height, and recoil pad position allow for a personalized fit.
Monopod rails
Part#: 02528-012-K1
This monopod rail from Cadex are engineered for precision shooting where maximum rear support is essential. Whether you’re using this standard monopod or require a flush cup integration, these rails provide a rock-solid foundation to improve your shooting accuracy in both tactical and competition settings.
Cadex rubberized grips
Part#: 03127-1075-BLK
Cadex Rubberized Grip delivers a secure, non-slip hold for improved comfort and control. Its finger-grooved design and textured rubber surface provide confident handling in all conditions, even with wet or gloved hands.
DX2 evo trigger
Part#: 6119-213-K1
The Cadex DX2 EVO trigger is a single/two stage trigger capable of being rapidly converted into a single stage trigger by its operator. Its trigger pull weight can be easily adjusted between 1.5 to 2.5 lb*.
*Achievable trigger pull weight can be influenced by multiple factors.
*Achievable trigger pull weight can be influenced by multiple factors.
interchangeable bolt knobs
Part#: BKNOB-I-K045
Durable 4140 steel bolt knob for improved bolt manipulation, reliable performance, and easy installation (Green Loctite® recommended).
Aics magazines
Part#: AICS-MAG
Accurate-Mag® AICS-pattern magazine offering reliable feeding and multiple caliber, length, and capacity options.
CDX-R7 series action
416 stainless steel
1.350" custom grade bolt action repeater (Rem 700 footprint) featuring a DLC coated 4 lug fluted bolt with an ultra-fast 50° short bolt throw, interchangeable pinned top rail in 0, 20 or 30 MOA, and ¼ turn tool-free bolt disassembly.
M-LOK competition tube
More mounting flexibility. Better balance. Built for competition.
Built for PRS-style competition shooting, the M-LOK Competition Tube offers greater flexibility for accessory placement and rifle setup. With multiple mounting positions, it allows shooters to customize their configuration for improved ergonomics, balance, and performance.
Barrel
Bartlein® barrel with single-point cut rifling
Bartlein® 1.238" straight taper fluted match grade barrel with 5R single-point cut rifling, threaded muzzle (MX1 included), and an easy do-it-yourself rebarreling system.
Small fore-end tube
Compact fore-end design with mirage mitigation technology.
The Small Fore-End Tube provides a compact and competition-focused platform with integrated mirage mitigation technology. It helps reduce heat distortion during extended shooting sessions while supporting barrels up to 1.800″ in diameter.
MX1 muzzle brake
Part#: 3850-028
The MX1 Muzzle Brake deliver exceptional performance by directing muzzle blast away from both the shooter and spotter. Engineered for real-world accuracy and comfort, these brakes channel gas sideways and upwards to reduce felt recoil, minimize dust cloud, and sharpen rifle control.
Chassis features
Hover over the numbers in the picture and have a tooltip with a description.
- Tool-free fully adjustable skeleton stock for length of pull, cheek piece and recoil pad height. Includes a neoprene cheek pad.
- Monopod rail or optional bean bag riders.
- Reverse folding buttstock offers bolt handle protection and ultra-compact transport.
- Finger-grooved Cadex rubberized grip.
- Oversized trigger guard and magazine release for easy manipulation with gloves.
- Optic can be mounted directly on the action using traditional scope bases, built-in action rail or optional Picatinny rail.
- Made from aircraft grade 6061-T6 aluminum billets, anodized and painted with a military grade non-reflective paint.
- Detachable base provides easy trigger access for maintenance and trigger adjustment. This allows the platform to maintain zero. Made of aluminum.
- AICS magazine compatible.
- Optional centre accessory rail kit (2) – Not shown.
- Spare screws.
- Optional centre bipod rail or tripod adaptor.
- A: Optional M-LOK bipod/sling adaptor.
B: Optional M-LOK aluminum bipod rail. - M-LOK competition fore-end tube featuring mirage mitigation technology. Longer tube for even more bipod positioning and stability.
- Maximum barrel diameter 1.800″.
Specifications
Available colors
Optional accessories
Cerakote coating
Specifications
The CDX-R7 short and long actions are designed to run standard large rifle primers.
Aftermarket brass using small rifle primers design isn’t recommended.
| Model | Caliber | Barrel length | Twist rate | Rifling | Magazine capacity | O.A.L.** | O.A.L. FOLDED** | APPROX. WEIGHT |
|---|---|---|---|---|---|---|---|---|
| CDX-R7 LCP SA (short action) | 6 Creedmoor* | 26" | 1:7½" | 5R | 10 | ± 45.0" | ± 36.5" | ± 13.6 lb |
| 6.5 Creedmoor* | 24" / 26" | 1:8" | 5R | 10 | ± 43.0" / 45.0" | ± 34.5" / 36.5" | ± 13.4 lb / 13.6 lb | |
| 6.5 PRC* | 24" / 26" | 1:8" | 5R | 7 | ± 43.0" / 45.0" | ± 34.5" / 36.5" | ± 13.4 lb / 13.6 lb | |
| 308 Win* | 20" / 24" / 26" | 1:11¼" | 5R | 10 | ± 39.0" / 43.0" / 45.0" | ± 30.5" / 34.5" / 36.5" | ± 13 lb / 13.4 lb / 13.6 lb | |
| 300 WSM* | 24" | 1:10" | 5R | 7 | ± 43.0" | ± 34.5 | ± 13.4 lb | |
| CDX-R7 LCP LA (long action) | 7 PRC | 26" | 1:8" | 5R | 5 | ± 45.9" | ± 37.3" | ± 13.8 lb |
| 300 PRC | 26" | 1:8" | 5R | 5 | ± 45.9" | ± 37.3" | ± 13.8 lb | |
| 300 Win Mag NEW | 26" | 1:10" | 5R | 5 | ± 45.9" | ± 37.3" | ± 13.8 lb | |
| 300 Norma Mag | 26" | 1:8" | 5R | 5 | ± 45.9" | ± 37.3" | ± 13.8 lb | |
| 338 Lapua Mag | 27" | 1:9½" | 5R | 5 | ± 46.9" | ± 38.3" | ± 13.9 lb |
*Available in left-handed with TriggerTech® primary trigger. **Dimensions do not include the muzzle brake.
DISCLAIMER: Too many components are involved to accurately predict the final weight of a rifle. It is impossible to confirm the weight because it varies depending on each caliber.
Available colors
Black (BLK)
Tan (Tan)
Hybrid Tan/Black (HTB)
O.D. Green (ODG)
Hybrid Green/Black (HOD)
Stealth Shadow Vortex (SSV)
Hybrid Stealth Shadow (HSB)
Sniper Grey (GRY)
Hybrid Grey/Black (HGB)
Stormtrooper White (WHT)
Hybrid White/Black (HWB)
Burnt Bronze (BRZ)
Hybrid BRONZE/Black (HBB)
Hunter Orange (ORG)
Hybrid Orange/Black (HOr)
ROBIN'S EGG BLUE (EGG)
Hybrid ROBIN'S EGG BLUE (HEB)
NRA Blue (NRA)
Hybrid NRA BLUE (HNR)
USMC red (RED)
Hybrid USMC RED (HUS)
Optional accessories
Cerakote coating
