Falcon Bipods Series
FALCON QD BIPOD – Part#: 7431-K015
FALCON AES BIPOD – Part#: 7431-K015AES
The Falcon Bipods have been designed to provide the ultimate stability. Two models are offered, Picatinny rail or AES (ARCA) mounting variants. It features multiple optional modular quick-change accessories such as spike, claw or ski feet. An optional Extension Leg kit is also available for the ELR game where shooters engage targets beyond 2 miles and require lots of bipod elevation without sacrificing the rifle’s stability.
The Falcon SP was designed to be adjustable to adapt to any given situation using a combination of different feet attachment and built-in features. The Single Pivot (SP) mount
allows the bipod to cant around a central pivot point rather than slide under. It is mainly manufactured using 6061-T6 aluminum and fiber reinforced polymers allowing it to be both light and sturdy.
FEATURES
FALCON QD BIPOD & FALCON AES BIPOD
- Fast-deployment legs without buttons to push.
- Ultra-tight machining tolerances for maximum stiffness and reduced
free play. - Reversible legs for choice of index or thumb push-button operation.
- Easy to operate the canting lever. Tilt angle +/- 15.5°.
- Folds/deploy forward, rearward 45° or standard 90°.
- Standard rubber feet, optional claw, spike or ski feet.
- Height is adjustable from 6.25″ to 8″.
- Incredibly stable (width from 11.4″ to 13.3″).
- Designed to withstand recoil up to 50 BMG.
- Adjustable height from approx. 6.25″ to 9″ depending on the model.
FALCON SP BIPOD
- All the same features as the regular Falcon bipod except that it cants around a central pivot point
- QD locking lever
- Picatinny attachment
- All the same features as the regular Falcon bipod except that it cants around a central pivot point
- QD locking lever
- Picatinny attachment
Folds forward or rearward
45° forward or rearward
90° shortened
90° extended
Shown with optional claw feet
for FALCON SP BIPOD – NEW
For more information, please refer to our Catalog (pdf-format or flipbook), or contact us at customerservice@cadexinc.com
Specifications
Falcon QD Bipod
Part#: 7431-K015
| Shortened: | 11.41″ x 5.19″ x 6.73″ | 28.97 x 13.18 x 17.09 cm |
| Extended: | 13.28″ x 5.19″ x 8.35″ | 33.73 x 13.18 x 21.21 cm |
| Folded: | 8.8″ x 5.1″ x 2.89″ | 22.35 x 12.96 x 7.33 cm |
| Weight (±): | 1.39 lbs | 630 grams |
| Material: | 6061-T6 aluminum |
| Shortened: | 11.41″ x 5.19″ x 6.73″ | 28.97 x 13.18 x 17.09 cm |
| Extended: | 13.28″ x 5.19″ x 8.35″ | 33.73 x 13.18 x 21.21 cm |
| Folded: | 8.8″ x 5.1″ x 2.89″ | 22.35 x 12.96 x 7.33 cm |
| Weight (±): | 1.39 lbs | 630 grams |
| Material: | 6061-T6 aluminum |
QD Picatinny mount
Falcon AES Bipod
Part#: 7431-K015AES
| Shortened: | 11.4″ x 3.98″ x 7.51″ | 28.96 x 10.12 x 19.07 cm |
| Extended: | 13.28″ x 3.98″ x 9.13″ | 33.72 x 10.12 x 23.19 cm |
| Folded: | 9.96″ x 5.1″ x 3.59″ | 25.3 x 12.95 x 9.13 cm |
| Weight (±): | 1.65 lb | 748 grams |
| Material: | 6061-T6 aluminum |
| Shortened: | 11.4″ x 3.98″ x 7.51″ | 28.96 x 10.12 x 19.07 cm |
| Extended: | 13.28″ x 3.98″ x 9.13″ | 33.72 x 10.12 x 23.19 cm |
| Folded: | 9.96″ x 5.1″ x 3.59″ | 25.3 x 12.95 x 9.13 cm |
| Weight (±): | 1.65 lb | 748 grams |
| Material: | 6061-T6 aluminum |
QD Arca Elite System mount
FALCON SP BIPOD NEW
Part#: 7431-K017SP
| Shortened: | 11.41″ x 4.3″ x 7.24″ | 28.98 x 10.92 x 18.39 cm |
| Extended: | 13.29″ x 4.3″ x 8.86″ | 33.76 x 10.92 x 22.5 cm |
| Folded: | 8.12″ x 5.1″ x 2.68″ | 20.62 x 12.95 x 6.8 cm |
| Weight (±): | 1.30 lb | 588 grams |
| Material: | 6061-T6 aluminum |
| Shortened: | 11.41″ x 4.3″ x 7.24″ | 28.98 x 10.92 x 18.39 cm |
| Extended: | 13.29″ x 4.3″ x 8.86″ | 33.76 x 10.92 x 22.5 cm |
| Folded: | 8.12″ x 5.1″ x 2.68″ | 20.62 x 12.95 x 6.8 cm |
| Weight (±): | 1.30 lb | 588 grams |
| Material: | 6061-T6 aluminum |
QD Picatinny mount
Options
Comparison Table
